Hensat 1.8 Meter Dish
Hensat 1.8-Meter Dish is a rugged, reliable antenna system that will operate at C-band or Ku-band frequencies with high efficiency and at the same time, successfully withstand the effects of the environment. This antenna features all aluminium metal reflectors, which consist of precisely formed panels with matched radials and hub assemblies for the ease of installation.
The reflector is supported by a galvanized steel fixed or motorizable pedestal that provides the required stiffness for pointing and tracking accuracy. It can be installed on the ground or rooftop.
SIZE GUIDE
| SIZE | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| BUST | 88 | 89 | 90 | 91 | 92 | 93 |
| WAIST | 55 | 56 | 58 | 59 | 62 | 65 |
| HIPS | 90 | 92 | 94 | 95 | 96 | 98 |
| SIZE | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| BUST | 60 | 62 | 65 | 66 | 68 | 69 |
| WAIST | 50 | 55 | 58 | 62 | 65 | 66 |
| HIPS | 80 | 82 | 85 | 86 | 88 | 89 |
Description
Features:
Superior electrical performance
Specialized feed systems
Hot-dip Galvanized structural steel
Guaranteed high-qualified antenna structure
Penetrating or Non-penetrating Mount
Faster and cheaper system implementation
Stainless Steel Hardware
Compact packaging design for ease and low-cost shipping
Responsive customer service support
Electrical Specification:
Diameter 1.8m
Operating Frequency, GHz C-Band Ku-Band
Receive Transmit Receive Transmit
3.625?4.2 5.85?6.425 10.95?12.75 14.0?14.5
Gain, Mid-band, dBi 45.3 46.5 46.9 47.5
Polarization Linear Linear
Cross Polarization Isolation (on Axis), dB ≥30
VSWR 1.25 1.25 1.25 1.25
Feed Interface CPR-229F CPR-159G WR-75 WR-75
Isolation, Tx to Rx, dB 85
Radiation Pattern: First Sidelobe ≤-14, Meet CCIR.580-4
Mechanical Specification
Antenna Optics Offset antenna
Azimuth 0°?360°
Elevation 1°?80°
Surface Accuracy (RMS) ≤ 0.5mm
Environmental Specification
Operational Wind Loading 14m/s (Gusting 20m/s)
Survival Wind Loading 54m/s
Temperature – 30°C ? + 50°C
Relative Humidity 100%
