NevoSwitch 5X5 MATV / FI Amplifier with gain of 27 / 25DB
Televes 5 inputs and 5 outputs Nevoswitch amplifier. The Televes 714509 NevoSwitch amplifier is a 5-input amplifier (one terrestrial and the four polarities of a satellite) that allows for increasing the number of users of the installation by optimizing the signal that reaches each one. This Televes amplifier has an approximate amplification of 27dB in terrestrial and 25dB in satellite.
SIZE GUIDE
| SIZE | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| BUST | 88 | 89 | 90 | 91 | 92 | 93 |
| WAIST | 55 | 56 | 58 | 59 | 62 | 65 |
| HIPS | 90 | 92 | 94 | 95 | 96 | 98 |
| SIZE | XS | S | M | L | XL | XXL |
|---|---|---|---|---|---|---|
| BUST | 60 | 62 | 65 | 66 | 68 | 69 |
| WAIST | 50 | 55 | 58 | 62 | 65 | 66 |
| HIPS | 80 | 82 | 85 | 86 | 88 | 89 |
Description
The Televes NevoSwitch amplifier allows, by means of a switch, to activate or deactivate the passage of current for the feeding of preamplifiers or active antennas. NevoSwitch amplifier with 5 inputs (one terrestrial and the four polarities of a satellite) that allows increasing the number of users of theinstallation by optimizing the signal that reaches each one.
Features:
High output level
Switch to feed ground preamps (VDC) or not (OFF)
Adjustment of gain (10dB) and slope (7dB) in an individualized manner
The feeding is carried out by the VL input/output
Very compact
Made of zamak
Identification of colours at the entrance and the exit
12V power
Reduced consumption
Specifications:
Type 5×5
Frequency margin MHz SAT 950 … 2400
RF 47 … 862
Input level dBμV SAT EN50083-3
IM35dBc 110
TERR DIN 45004-B 110
DB SAT gain 25
TERR 27
Regulation 10
Slope 0 … 7
DB insulation> 25
Step DC In-Out / Out-In
Max consumption total mA PSU (3) 160
Temperature Range ºC -5 … + 45
IP protection index 20
